YOOKSMART MOTOR
Our every motor has undergone 100% quality inspection
before delivery. We have qualified the ISO9001 Certification, ISO 14001 Environmental Management System
Certification, CCC China Compulsory Certification and CE Certification.
These certificates reflect our commitment to strict control of product quality. We have set up various testing
labs and lifecycle test stations which perform 14000 cycles continuous lifecycle test on thousands of randomly
selected motors.
yooksmart smart MOTOR
| Diameter(mm) | 25/28/35 | 45 |
|---|---|---|
| Application | Roller Shade / Zebra Shade / Sheer Shade | |
| Signal | RF / Wifi / Zigbee / Blue Tooth | |
| Smart Device | Alex / Google home / Home Kit / IFTTT | |
| Power Supply | Lithium Battery / Solar Panel / Hardwired | |
| Length（mm） | 260~540 | 440~720 |
| Rated Torque(Nm) | 0.7~10 | 6~65 |
| Rated Rotation Speed（Rpm） | 9~30 | 12~30 |
| Wireless Frequency(MHz) | 433.92/2.4G/2.4~2.4835GHz | 433.92/2.4G/2.4~2.4835GHz |
| Running Noise(dB) | 35～45 | 35～50 |
| Max.Load(kg) | 14 | 90 |
| Input Voltage(V) | 5~12/100~240 | 12/24/120/230 |
| Rated Power（W） | 7~36/85/115~130 | 36~330 |
| Rated Current(A) | 0.1~3 | 0.485~7.5 |
| Protection Class(IP) | 44 | 44/65 |
| Working Temp | -20 ～ +55℃ | -10 ～ +55℃ |
| Diameter(mm) | 24 | 40 |
|---|---|---|
| Application | Venetian Blind / Cellular Shade / Roman Shade | |
| Signal | RF/ Wifi / Zigbee | |
| Smart Device | Alex / Google home / Home Kit / IFTTT | |
| Power Supply | Lithium Battery / Solar Panel / Hardwired | |
| Length（mm） | 193~208 | 290~320 |
| Rated Torque(Nm) | 0.6~0.8 | 2 |
| Rated Rotation Speed（Rpm） | 34 | 28 |
| Wireless Frequency(MHz) | 433.92 | 433.92 |
| Running Noise(dB) | 35 | 37 |
| Max.Load(kg) | 5 | 12 |
| Input Voltage(V) | DC 7.4~24 | DC 12~24 |
| Rated Power（W） | 10~13 | 18~20/72 |
| Rated Current(A) | 0.4~1.8 | 0.8~3 |
| Protection Class(IP) | 20~44 | 40~44 |
| Working Temp | -10 ~ +65℃ | -20 ~ +55℃ |
| Diameter(mm) | 40 * 40 | 50 * 50 |
|---|---|---|
| Application | Drapery | Vetical Blind/Sheer Blind |
| Signal | Wifi | |
| Smart Device | Alex / Google home / Home Kit / IFTTT | |
| Power Supply | Hardwired | |
| Length（mm） | 270 | 275 |
| Rated Torque(Nm) | 1.2 | 1.1 |
| Rated Rotation Speed（Rpm） | 85 | 90 |
| Wireless Frequency(MHz) | 2.4G | 2.4G |
| Running Noise(dB) | 34 | 40 |
| Max.Load(kg) | 50 | 35 |
| Input Voltage(V) | DC24 | AC100 ~240 |
| Rated Power（W） | 31.2 | 54 |
| Rated Current(A) | 1.3 | 0.075 |
| Protection Class(IP) | 41 | 20 |
| Working Temp | -5 ~ +50℃ | -10 ~ +60℃ |
